Anucha Metals offers high-strength Aluminium 7075 Bar and Rods, made in Bangkok, Thailand, for industries demanding maximum performance under stress. As one of the strongest commercially available aluminium alloys, 7075 is popular in aerospace, automotive, and defense sectors. These bars and rods are heat-treatable and provide excellent fatigue resistance with a superior strength-to-weight ratio. Our products meet international standards, including ASTM and AMS specifications. Anucha Metals supplies 7075 bars and rods in both custom and standard sizes to fit structural, precision, and performance-focused engineering applications.
Aluminium 7075 consists of about 90% aluminium, 5.6% zinc, 2.5% magnesium, and 1.6% copper. It is heat-treatable, achieving tensile strength up to 570 MPa and yield strength around 500 MPa (T6). It offers excellent fatigue strength, high hardness, and good machinability. Corrosion resistance is moderate but can be enhanced through cladding or anodizing. Its stability after machining helps retain strength in demanding conditions.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 7075 bar is commonly used for structural applications due to its high strength, excellent corrosion resistance, and lightweight properties, making it suitable for aerospace, automotive, and military structural components.
Aluminium 7075 rods are sized based on their diameter and length. Diameters typically range from 1/8" to 12", and lengths vary from 3' to 20', depending on specific customer requirements.
To maintain Aluminium 7075 bar, regularly clean it with mild soap and water to remove dirt. Avoid harsh chemicals, and store it in a dry, cool environment to prevent corrosion and damage.
7075 bars and rods are suitable for aerospace components like wing spars, bulkheads, and fuselage parts. In automotive and motorsports, they are used for suspension parts, drivetrain components, and chassis reinforcements. The alloy is also chosen for bicycle frames, climbing gear, firearm parts, and precision jigs. Its strength and reliability under fatigue make it important in performance engineering, especially where weight savings and structural integrity are critical.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
