Anucha Metals is a notable manufacturer and exporter of Aluminium 2014 bars and rods in Bangkok, Thailand. Aluminium 2014 is a high-strength alloy often used in aerospace and structural applications. It is known for excellent machinability and mechanical strength, and our bars are produced with strict tolerances and uniform grain structure. We supply custom and standard-sized bars for industries needing high-performance aluminium. Anucha Metals guarantees consistency, certification, and performance across all orders, helping clients meet demanding engineering specifications.
Aluminium 2014 is an aluminium-copper alloy that contains about 4.4% copper, 0.8% manganese, and 0.5% magnesium. It has a tensile strength of 440 to 483 MPa and a yield strength of about 400 MPa. The alloy offers excellent machinability and good fatigue resistance; however, it has lower corrosion resistance. It is typically used in a heat-treated state to achieve desired mechanical properties.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Aluminium 2014 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.7 | 0.50 – 1.20 | 0.2 – 0.8 | 0.4 – 1.2 | 3.9 – 5.0 | 0.25 | 0.15 | 93.5 |
| Material | Temper | Diameter (mm) | Tensile Strength min ((N/mm²) | Yield Strength (min) (N/mm²) | Elongation on 5.65 V (min) |
| 2014 Bar | T4 | <20 | 370 | 230 | 11 |
| 2014 Bar | T4 | 20-75 | 390 | 250 | 11 |
| 2014 Bar | T4 | 75-150 | 390 | 250 | 9 |
| 2014 Bar | T4 | 150-200 | 370 | 230 | 8 |
| 2014 Bar | T6510 | 20-75 | 480 | 435 | 7 |
| 2014 Bar | T6510 | 75-150 | 465 | 420 | 7 |
| 2014 Bar | T6510 | 150-200 | 435 | 390 | 7 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2014 | A92014 | 3.1255 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
To maintain Aluminium 2014 bars, regularly clean them with mild soap and water to prevent corrosion. Avoid exposure to harsh chemicals and extreme temperatures, and inspect for signs of fatigue or wear.
Aluminium 2014 bars and rods are not ideal for high-temperature applications. While they offer high strength, their performance decreases at elevated temperatures, limiting their suitability for environments above 150°C (302°F).
Aluminium 2014 rods are sized by their diameter, typically ranging from small (e.g., 6 mm) to large (e.g., 100 mm), and are available in various standard or custom lengths.
Aluminium 2014 bars and rods are used in aerospace structures, military vehicles, fasteners, and high-strength industrial components. They are also used in machinery parts, structural supports, and automotive assemblies. Due to their high strength-to-weight ratio, they are preferred in applications that need strong yet lightweight materials. Anucha Metals provides Aluminium 2014 products tailored to meet mechanical performance needs in critical environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
