Anucha Metals stands out as a prominent manufacturer and supplier of Copper Nickel Square Bars right in the heart of Bangkok, Thailand. They take pride in delivering top-notch products that are designed to perform exceptionally well, even in the toughest conditions. These Copper Nickel Square Bars are celebrated for their remarkable resistance to corrosion, impressive durability, and precise engineering, making them a go-to choice in various sectors like marine, oil & gas, chemical, and power generation. The company is committed to upholding international standards, employing advanced manufacturing techniques, and conducting thorough quality checks, ensuring that their products reliably meet a wide range of industrial demands. With a wealth of expertise and a dedication to excellence, Anucha Metals has earned a reputation as a trusted global supplier of Copper Nickel Square Bars.
These bars are primarily made up of copper (60–90%) and nickel (10–40%), with carefully controlled amounts of iron and manganese added to boost their mechanical strength and resistance. They excel in resisting seawater corrosion, biofouling, and stress corrosion cracking. On the mechanical side, they provide solid tensile and yield strength, toughness, and ductility, along with impressive thermal stability and conductivity. Plus, Copper Nickel Square Bars are known for their excellent weldability, machinability, and formability, which contribute to their long-lasting durability. This unique blend of corrosion resistance and mechanical performance makes them an ideal choice for both marine and industrial applications.
| Standard | ASTM B111, ASME SB111 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Mn | Cu | Pb | Fe | Ni | Zn |
|---|---|---|---|---|---|---|
| 90/10 | 1.0 max | 88.6 min | 0.5 max | 1.8 max | 9-11 max | 1 max |
| 70/30 | 1 max | 65.0 min | 0.5 max | 0.4-1.0 | 29-33 | 1 max |
| Grade | Melting point | Density | Tensilestrength | Elongation | Yieldstrength(0.2%Offset) |
|---|---|---|---|---|---|
| 90/10 | 2260°F | 8.8g/cm3 | 50000 PSi | 30% | 20000 PSi |
| 70/30 | 2260°F | 0.323 lb/in3 at 68°F | 50000 PSi | 30% | 20000 PSi |
| BD | Bright drawn | SRE | Slit rolled edge |
| CF | Cold finished | HRAP | Hot rolled annealed / pickled |
| CG | Centreless ground | HF | Hot finished |
| ST | Smooth turned | PR | Peeled / reeled |
| CD | Cold drawn | P | Polished |
| P&T | Peeled / turned | RT | Rough turned and peeled |
| Metric | US Rods | ASTM/ Canadian | Japanese | ||||
|---|---|---|---|---|---|---|---|
| Rods Size | Diam. (mm) | Rods Size | Diam. (Inch) | Rods Size | Diam. (mm2) | Rods Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.600 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.600 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Grade | UNS | Werkstoff Nr. |
| 90/10 | C70600 | 2.0872 |
| 70/30 | C71500 | 2.0882 |
Yes, Copper Nickel Square Bars are customizable. They can be tailored in terms of size, shape, length, and specific alloy composition to meet the precise requirements of various industrial applications.
In various industries that demand corrosion resistance, durability, and longevity, Copper Nickel Square Bars are widely utilized. In the marine sector, they play a crucial role in shipbuilding, propeller shafts, seawater piping, and condenser systems. The oil & gas industry relies on them for offshore platforms, desalination plants, and subsea pipelines. In power generation, they are essential for cooling systems, heat exchangers, and condenser tubes. The chemical and petrochemical sectors use them for equipment that handles corrosive fluids. Additionally, Copper Nickel Square Bars are also found in food processing applications, showcasing their versatility and reliability across different fields.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Anucha Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Bangkok, Thailand
