Anucha Metals, based in Bangkok, Thailand, provides high-quality Aluminium 6063 Bar and Rods designed for structural, architectural, and decorative uses. Known for its smooth surface and strong corrosion resistance, Aluminium 6063 is often referred to as the “architectural alloy.” It is easy to machine, weld, and anodize, making it suitable for both indoor and outdoor projects. Our bars and rods are made to international standards and can be customized to specific dimensions. With a commitment to precision and aesthetics, Anucha Metals guarantees top performance and appearance for every 6063 bar and rod we deliver.
Aluminium 6063 consists of about 97.5% aluminium, 0.6% magnesium, and 0.4% silicon. It is heat-treatable and provides a tensile strength of 190 to 240 MPa and a yield strength of 160 to 200 MPa, depending on the temper (T5 or T6). The alloy offers a great surface finish, moderate strength, good corrosion resistance, and easy fabrication. It is perfect for precision profiles and retains strength after extrusion and machining. Anodizing improves both its appearance and durability.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Cu | Si | Fe | Mn | Mg | Zn | Cr | Ti | Other Each | Others Total | Al |
| .10 (max) | .20/.60 | .35 (max) | .10 (max) | .45/.90 | .10 (max) | .10 (max) | .10 (max) | .05 | .015 | Remainder |
| Tensile Strength (psi) | Yield Strength (psi) | Elongation (% in 2″) | Brinell Hardness |
| 27,000 | 21,000 | 12 | 60 |
| UNS | EN | DIN, WNR | ISO | BS (OLD) | USA | WNR |
| A96063 | AW-AlMg0,7Si EN AW-6063 | AlMgSi0.5 | AlMg0,7Si | HE9 | AA6063 | 3.32206 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6063 rods can be customized in size and length according to specific requirements. Manufacturers offer flexibility in dimensions to meet various application needs and industry standards.
To maintain Aluminium 6063 bars, clean regularly with mild soap and water, avoid harsh chemicals, and inspect for scratches or corrosion. For enhanced longevity, apply a protective coating if needed.
Yes, Aluminium 6063 bars are highly recyclable. Aluminium can be reused indefinitely without losing quality, making it an eco-friendly choice. Recycling helps conserve resources and reduces energy consumption in production.
6063 bars and rods are commonly used in window frames, doors, curtain walls, and other architectural features because of their clean finish and corrosion resistance. They are used in transportation for trim, rails, and interior fittings. In electronics, they are perfect for heat sinks and enclosures. 6063 is also used for piping, furniture, and automotive decorative trims. Its good anodizing properties make it suitable for colored finishes and UV exposure. For both indoor and outdoor structural applications, 6063 provides a combination of strength, formability, and visual appeal.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
