Anucha Metals, a well-respected manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality Stainless Steel 410 Square Bars and Rods that meet international industry standards. Renowned for their durability, precision, and performance, Anucha Metals guarantees that their products can handle the toughest industrial applications with ease. Stainless Steel 410, a martensitic stainless steel grade, is prized for its impressive strength, hardness, and decent corrosion resistance. These square bars and rods find their way into various industries, including automotive, construction, chemical, and engineering, providing reliable solutions for both structural and mechanical needs.
The composition of Stainless Steel 410 Square Bars and Rods primarily includes iron, with 11.5–13.5% chromium, up to 1% manganese, 1% silicon, 0.15% carbon, along with trace amounts of sulfur and phosphorus. This martensitic grade can be heat-treated, allowing it to achieve higher hardness and strength compared to many other stainless steels. It boasts a tensile strength ranging from 450 to 650 MPa, a yield strength of about 205 MPa, an elongation of 20%, and a Brinell hardness of 170–220 in its annealed state. With the right heat treatment, Stainless Steel 410 can enhance wear resistance and mechanical stability, making it suitable for high-performance applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 410 | 0.15 | 11.5-13.5 | 1.00 | 0.75 | 0.040 | 0.030 | 1.00 |
| Tempering Temperature (°C) | Tensile Strength (MPa) | Yield Strength 0.2% Proof (MPa) | Elongation (% in 50 mm) | Hardness Brinell (HB) | Impact Charpy V (J) |
|---|---|---|---|---|---|
| Annealed * | 480 min | 275 min | 16 min | – | – |
| 204 | 1475 | 1005 | 11 | 400 | 30 |
| 316 | 1470 | 961 | 18 | 400 | 36 |
| 427 | 1340 | 920 | 18.5 | 405 | # |
| 538 | 985 | 730 | 16 | 321 | # |
| 593 | 870 | 675 | 20 | 255 | 39 |
| 650 | 300 | 270 | 29.5 | 225 | 80 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 410 | 1.4006 | S41000 | SUS 410 | 410S21 | – | – | 56A |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 410 square bars can be welded, but preheating and post-weld heat treatment are often recommended to avoid cracking. Proper welding techniques ensure strong, durable joints.
To ensure the quality of Stainless Steel 410 square bars, source them from reputable suppliers and conduct material testing, such as tensile strength and hardness tests. Additionally, check for proper surface finish and dimensional accuracy.
Yes, we provide 410 Stainless Steel Square Bars and Rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@anuchametal.com
Stainless Steel 410 Square Bars and Rods are widely utilized in industries that require strength, hardness, and moderate corrosion resistance. In the automotive field, they are commonly used for fasteners, shafts, and valve components. The construction and engineering sectors rely on them for structural supports, frameworks, and machine parts that demand durability. Additionally, they are found in pump shafts, surgical instruments, and turbine blades, where wear resistance and toughness are essential. Thanks to their excellent machinability, heat-treatability, and mechanical strength, Stainless Steel 410 Square Bars and Rods are perfect for a broad range of critical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
