Anucha Metals, a top-notch manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality Stainless Steel 316L Hex Bars and Rods that are built to resist corrosion and last over time. These hex bars and rods are designed to withstand pitting, crevice corrosion, and oxidation, making them perfect for a variety of applications in chemical, marine, and industrial settings. Thanks to their low carbon content, Stainless Steel 316L not only offers outstanding weldability but also reduces carbide precipitation, ensuring they maintain their structural integrity even in tough environments. Anucha Metals prides itself on delivering precision-engineered products that adhere to international standards, catering to industries like chemical processing, oil & gas, marine, food processing, and pharmaceuticals with dependable, high-performance stainless steel solutions.
The composition of Stainless Steel 316L Hex Bars and Rods includes 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and low carbon content, along with small amounts of manganese and silicon. This unique blend boosts their corrosion resistance, weldability, and durability in challenging conditions. On the mechanical side, they boast a tensile strength ranging from 485–690 MPa, yield strength between 170–310 MPa, and an elongation of up to 40%. The alloy is known for its excellent toughness, resistance to stress corrosion, and dimensional stability, making it ideal for high-stress and corrosive industrial applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 316L Hex Bars/Rods offer exceptional resistance to corrosion, including pitting and crevice corrosion caused by chlorides, due to their chromium and molybdenum content. Their low carbon levels prevent sensitization, ensuring durability in marine and chemical environments.
SS 316L Hex Bars/Rods are used in marine, chemical processing, food, pharmaceutical, and oil and gas industries. Their superior corrosion resistance enhances longevity and performance, particularly in environments exposed to chlorides, acids, alkalis, and high-moisture conditions.
Yes, SS 316L Hex Bars/Rods are easily welded and machined due to their low carbon content. However, precautions include using appropriate tools to avoid work hardening, maintaining low heat input during welding, and employing post-weld cleaning to prevent contamination.
You’ll find Stainless Steel 316L Hex Bars and Rods widely used in chemical and petrochemical equipment, piping systems, and heat exchangers that come into contact with corrosive substances. They’re also a great fit for marine applications, such as seawater systems, shipbuilding, and offshore platforms. In the food and pharmaceutical sectors, these materials are essential for hygienic machinery and processing equipment. Moreover, they find applications in oil & gas, power generation, and architectural structures that demand durability, corrosion resistance, and mechanical strength. The combination of these properties makes Stainless Steel 316L Hex Bars and Rods both versatile and reliable for even the most demanding industrial environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
