Anucha Metals, a top-notch manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality Inconel 617 Forgings that are celebrated for their outstanding performance in extreme temperatures and harsh environments. Crafted using cutting-edge technology and adhering to rigorous quality standards, these forgings are well-known for their remarkable resistance to oxidation, carburization, and creep. Inconel 617, which is a nickel-chromium-cobalt-molybdenum alloy, is engineered to retain its strength and stability even in the most intense thermal conditions. Anucha Metals guarantees durability, precision, and reliability, making Inconel 617 Forgings the go-to choice for sectors like aerospace, power generation, chemical processing, and marine engineering.
These Inconel 617 Forgings are primarily made up of nickel, chromium, cobalt, and molybdenum, with a touch of aluminum added in. This well-balanced composition offers excellent resistance to oxidation, carburization, and hot corrosion at high temperatures. On the mechanical side, these forgings boast impressive tensile strength, outstanding creep resistance, and remarkable toughness, even when faced with severe thermal cycling. Their stable microstructure ensures a long service life and dependable performance in challenging environments, making Inconel 617 Forgings a reliable material for high-stress industrial applications that demand both strength and corrosion resistance.
Specifications ASTM B564 / ASME SB 564, AMS 5887
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | UNS | WNR. |
| Alloy 617 | N06617 | 2.4663 |
Temperature control during forging of Inconel 617 ensures optimal grain structure, improving its strength, durability, and resistance to thermal creep. Proper temperature management also prevents material defects like cracking or distortion, enhancing overall quality.
Inconel 617 forgings may experience reduced ductility at lower temperatures, limiting their ease of fabrication. Additionally, they can be costly due to the complex alloy composition and manufacturing processes.
Inconel 617 forgings require periodic inspections to detect signs of oxidation or wear, particularly at elevated temperatures. Regular cleaning and protective coatings can help maintain their performance in harsh, high-temperature environments.
Inconel 617 Forgings find their place in various industries that require durability under extreme conditions. In aerospace, they are utilized in combustion cans, transition liners, and turbine components. Power generation facilities use them in gas turbines, heat exchangers, and boiler systems that endure prolonged thermal stress. The chemical and petrochemical sectors incorporate them in reactors, piping, and high-temperature furnaces that handle corrosive materials. Moreover, Inconel 617 Forgings are also employed in marine applications, automotive parts, and specialized engineering projects where long-lasting performance, oxidation resistance, and structural integrity at elevated temperatures are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Anucha Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Bangkok, Thailand
