Anucha Metals, a trusted manufacturer and supplier based in Bangkok, Thailand, has earned a solid reputation for delivering top-notch Super Duplex Steel Ferralium 255 Bars and Rods to clients around the globe. Known for their commitment to excellence and precision, the company guarantees that each product adheres to international quality standards. Super Duplex Steel Ferralium 255 is celebrated for its remarkable corrosion resistance, outstanding strength, and durability, making it perfect for even the toughest environments. Anucha Metals caters to a variety of industries, including oil & gas, petrochemical, marine, and construction, ensuring reliable performance and long-lasting dependability.
These Super Duplex Steel Ferralium 255 Bars and Rods are crafted from a blend of chromium, nickel, molybdenum, and copper, with added nitrogen, resulting in a well-balanced austenitic-ferritic structure. This unique makeup provides exceptional resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. Their mechanical properties boast a high yield strength of about 550 MPa, tensile strength ranging from 750 to 950 MPa, and impressive impact toughness, even in low temperatures. Additionally, they offer good ductility, excellent fatigue resistance, and low thermal expansion. These characteristics make Ferralium 255 Bars and Rods a reliable choice for demanding engineering and industrial applications that require both strength and corrosion resistance.
| Grade | Ferralium 255 |
|---|---|
| Specification | Super Duplex Steel Ferralium 255 Round Bar |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Section | 3.0 to 12.0mm thickness |
| Round bar size | Diameter: 3-~800mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Billet Size | 1/2″ to 495mm Diameter | Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Technique | Ferralium 255 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Ferralium 2507 Round Bar, Rod, T-Bar, Super Duplex Steel Channel Bar, Precision Ground Bar, Super Duplex Steel Flat Bar, Super Duplex Steel Square Bar, Super Duplex Steel Blocks, Super Duplex Steel Round Rod, Super Duplex Steel Rings, Super Duplex Steel Hollow, Super Duplex Steel Triangle, Rectangle, Hex (A/F), Super Duplex Steel Threaded, Ferralium 2507 Half Round Bar, Profiles, Super Duplex Steel Billet, Super Duplex Steel Ingot, I/H Bar, Forging etc. |
| Mo | Cu | Cr | Ni | N | Si | Mn | W | P | S | C | Fe |
| 3.5 | 1.75 | 26 | 6.3 | 0.23 | 0.15 | 0.5 | 1 max | 0.025 max | 0.025 max | Balance | 0.005 max |
| Yield Strength (0.2%Offset) | MPa – 570-600 |
| Tensile Strength | MPa – 790 |
| Elongation | 25 % |
| STANDARD | UNS | DIN |
|---|---|---|
| Ferralium 2507 round bar | S32550 | 1.4507 |
Yes, Super Duplex Steel Ferralium 255 Bars can be welded using suitable techniques like TIG, MIG, or SMAW, ensuring precise heat input control to prevent phase imbalance. Pre-heating and post-weld heat treatments may be required for optimal weld integrity.
Super Duplex Steel Ferralium 255 Rods are highly resistant to galvanic corrosion due to their excellent corrosion resistance properties. However, they may still experience some susceptibility in highly corrosive environments when coupled with more anodic materials.
Super Duplex Steel Ferralium 255 rods are available in a wide range of sizes, typically from 3mm to 500mm in diameter. They are offered in finishes such as hot-rolled, cold-drawn, and polished for various applications.
Super Duplex Steel Ferralium 255 Bars and Rods are extensively utilized across various industries due to their exceptional performance in challenging conditions. In the oil and gas sector, they find applications in offshore platforms, subsea equipment, and pipelines. The marine industry employs them for propeller shafts, pumps, and seawater cooling systems, thanks to their resilience against saline environments. Chemical and petrochemical industries depend on them for pressure vessels, heat exchangers, and reactors. They are also used in desalination plants, pulp and paper processing, and structural applications. Their strength, toughness, and corrosion resistance make them a go-to choice for demanding projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
