Anucha Metals, a reputable manufacturer and supplier located in Bangkok, Thailand, specializes in high-quality Phosphorous Bronze Bars and Rods tailored to meet a variety of industrial requirements. Renowned for their exceptional strength, outstanding wear resistance, and durability, these bars and rods are meticulously crafted using advanced technology. Phosphorous Bronze is highly regarded for its toughness, resistance to corrosion, and longevity, making it perfect for demanding applications. Anucha Metals is committed to delivering consistent quality, competitive prices, and prompt delivery, catering to industries like marine, automotive, electrical, and heavy machinery with dependable bronze solutions.
Phosphorous Bronze Bars and Rods mainly consist of copper (about 90–95%), tin (3.5–10%), and a small amount of phosphorus (0.01–0.35%). The addition of phosphorus boosts wear resistance, fatigue strength, and stiffness while enhancing corrosion resistance. These alloys showcase impressive mechanical strength, excellent elasticity, and favorable spring properties. They provide tensile strength ranging from 350–800 MPa, along with good ductility and fatigue resistance. The blend of toughness and machinability makes Phosphorous Bronze ideal for high-performance and precision engineering applications.
| Specifications | AMS 4625, ASTM B139, ASME SB139 |
| Phosphor Bronze Round bar size | Diameter: 3mm~800mm |
| Phosphor Bronze Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Phosphor Bronze Square bar size | 4mm*4mm~100mm*100mm |
| Phosphor Bronze Flat bar size | Thickness: 2mm~100mm |
| Width: 10mm~500mm | |
| Phosphor Bronze Hex Bar size | 2mm~100mm |
| Phosphor Bronze Billet Size | 1/2″ to 495mm Diameter |
| Phosphor Bronze Rectangles Size | 33mm x 30mm to 295mm x 1066mm |
| Finish | Bright, Polish, Bright, Rough Turned, Grinding, Centreless Ground & Black |
| Length | 1000mm-6000mm |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Condition | Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished, Annealed round bar |
| Technique | Phosphor Bronze Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Form | Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc. |
| Alloy number | Sn | P | Pb | Zn | Cu+Sn+P |
| C5191 | 5.5-7.0 | 0.03-0.35 | ≥99.5 | ||
| C5441 | 3.0-4.5 | 0.01-0.50 | 3.5-4.5 | 1.5-4.5 | ≥99.5 |
| Grade B.S. 1400: 1985 | Nominal Composition | 2% PS N/mm Min | Tensile Strength N/mm Min | Elongation % Min | Brinell Hardness Min |
| PB1 | 89/10/01 | 130 | 250 | 5 | 60 |
| PB1 | 88/12 | 140 | 260 | 7 | 80 |
| PB1 | 90/10 | 130 | 250 | 5 | 60 |
| PB1 | 90.5/9.5 | 130 | 240 | 5 | 80 |
| LPB-1 | 87/8/2/3 | 80 | 175 | 7 | 60 |
| Pb2 | 88/12 | 120 | 195 | 5 | 60 |
| Pb2 PB | 88/12 95/5 | 145 130 | 295 240 | 5 5 | 80 80 |
Phosphorus bronze bars can be welded, but it requires care. The material tends to be brittle at high temperatures, so preheating and using appropriate filler materials are recommended for successful welding.
To select the right phosphorous bronze bar, consider factors such as tensile strength, corrosion resistance, conductivity, the specific environmental conditions, required durability, and mechanical properties for your application.
To select the right phosphorous bronze bar, consider factors such as tensile strength, corrosion resistance, conductivity, the specific environmental conditions, required durability, and mechanical properties for your application.
Phosphorous bronze rods are available in diameters ranging from 1/8" to 12" and lengths up to 20 feet. Finishes include hot-rolled, cold-rolled, extruded, polished, and custom-machined.
Phosphorous Bronze Bars and Rods are extensively utilized across various industries due to their durability, wear resistance, and electrical conductivity. In the marine industry, they are commonly found in ship propellers, pump components, and marine fittings because of their excellent corrosion resistance. In the automotive and aerospace fields, they are used in bearings, bushings, and gears where toughness and fatigue resistance are crucial. The electrical sector employs them in connectors, switchgear, and springs due to their superior conductivity and resilience. Their reliability in high-stress environments makes them indispensable in heavy engineering and precision machinery.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
