Anucha Metals is a reliable manufacturer and supplier of Nitronic 50 Bars and Rods based in Bangkok, Thailand. We take pride in offering top-notch stainless steel products that are built for strength, durability, and outstanding resistance to corrosion. Our Nitronic 50 bars and rods are well-known for their impressive ability to withstand pitting, crevice corrosion, and chloride stress corrosion cracking, making them perfect for tough environments. With their high mechanical strength, remarkable toughness, and good weldability, these products are crafted to meet international standards, ensuring precision, reliability, and a long lifespan. Anucha Metals caters to various industries, including marine, chemical processing, oil and gas, and pulp and paper, providing high-performance Nitronic 50 solutions.
The composition of Nitronic 50 Bars and Rods features austenitic stainless steel enriched with chromium, nickel, molybdenum, and nitrogen, which boost both strength and corrosion resistance. This alloy offers nearly double the yield strength of standard stainless steels while still maintaining excellent toughness, even in freezing temperatures. Its well-balanced makeup ensures superior resistance to seawater and other chloride-rich environments, along with good fabricability and weldability. Nitronic 50 merges the corrosion resistance of 316 stainless steel with significantly enhanced mechanical properties, making it a versatile option for demanding applications.
| Grade | Nitronic Alloy 50 / XM-19 (UNS No. S20910) |
|---|---|
| Specification | DIN, JIS, ASTM, BS, ASME, AISI |
| Nitronic 50 Square bar size | 4 to 100mm |
| Nitronic Alloy 50 Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Nitronic Alloy UNS S20910 Hex Bar size | 2-100mm A/F |
| Nitronic 50 Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Nitronic Alloy 50 Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Nitronic Alloy UNS S20910 Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Nitronic 50 Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Nitronic Alloy 50 Section | 3.0 to 12.0mm thickness |
| Nitronic Alloy UNS S20910 Round bar size | Diameter: 3-~800mm |
| Nitronic 50 Billet Size | 1/2″ to 495mm Diameter |
| Nitronic Alloy 50 Round Bar Standard Dimensions | Diameter / Height: |
| Nitronic 50 Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Nitronic Alloy 50 Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Nitronic Alloy UNS S20910 Technique | Nitronic 50 Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Nitronic 50 Condition | Hardened & tempered, annealed |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Form | Nitronic 50 Round, Rod, T-Bar, Nickel Alloy Channel Bar, Precision Ground Bar, Nickel Alloy Flat Bar, Nickel Alloy Square Bar, Nickel Alloy Blocks, Nickel Alloy Round Rod, Nickel Alloy Rings, Nickel Alloy Hollow, Nickel Alloy Triangle, Rectangle, Hex (A/F), Nickel Alloy Threaded, Half Round Bar, Profiles, Nickel Alloy Billet, Nickel Alloy Ingot, I/H Bar, Forging etc. |
| Processing | Bar cutting to 650mm |
| Our Nitronic 50 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | S | Si | N | Ni | Cr |
| Nitronic Alloy 50 | .06 | .10 | 0.03 | 1.00 | 0.20 – 0.40 | 11.50 – 13.50 | 20.50 – 23.50 |
| Hardness MAX, Brinell | 241 |
| Ultimate Tensile Strength, ksi | 95 |
| 0.2% Yield Strength, ksi | 50 |
| Elongation, % | 35 |
| Reduction of Area, % | 55 |
| STANDARD | UNS | DIN |
|---|---|---|
| Nitronic 50 | S20910 | 1.3964 |
Nitronic 50 rods typically come in diameters ranging from 1/8" to 6" and lengths from 12" to 144". Custom sizes may also be available based on specific requirements.
Yes, Nitronic 50 bar can be welded using conventional methods like TIG and MIG welding. However, proper preheat and post-weld heat treatment are recommended for optimal results.
Nitronic 50 rods are available in various sizes, ranging from 1/8" to 12" in diameter. Finishes include mill, polished, and ground, depending on specific requirements and applications.
Nitronic 50 Bars and Rods find extensive use in industries that demand both strength and corrosion resistance under challenging conditions. They are frequently utilized in marine settings for pump shafts, fasteners, and hardware that come into contact with seawater. In the chemical and petrochemical sectors, they serve in heat exchangers, reactors, and piping systems. Offshore oil and gas platforms depend on them for components that face harsh, corrosive environments. The pulp and paper industry also employs them in bleaching and processing equipment. Their exceptional balance of mechanical strength and corrosion resistance makes them a go-to choice for various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
