Anucha Metals, a reputable manufacturer and supplier located in Bangkok, Thailand, specializes in high-quality MP35N Bars and Rods that are crafted to meet the toughest industrial standards. Renowned for their incredible strength, resistance to corrosion, and biocompatibility, MP35N alloys are a go-to choice in some of the most challenging environments. Anucha Metals prides itself on delivering top-notch quality and precise manufacturing practices, making them a dependable source for these specialized alloys. With a strong focus on customer satisfaction, they offer MP35N Bars and Rods that consistently perform well across various sectors, including aerospace, medical, oil & gas, and marine industries.
MP35N Bars and Rods are made from a nickel-cobalt-chromium-molybdenum alloy that boasts impressive mechanical and chemical properties. Typically, the composition consists of about 35% nickel, 35% cobalt, 20% chromium, and 10% molybdenum. This unique combination results in ultra-high tensile strength, excellent fatigue resistance, and outstanding resistance to stress-corrosion cracking. MP35N is known for its remarkable toughness, ductility, and high hardness, even under extreme temperatures. Its biocompatibility makes it ideal for medical uses, while its exceptional wear resistance and ability to endure harsh conditions ensure long-lasting performance across various critical industries.
| Standards : | ASTM F562 / ASME SF562 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Round Bar, Wire |
| Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
|
Cr |
20 nom |
|
Ni |
35 nom |
|
Mo |
10 nom |
|
Co |
35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
| PHYSICAL PROPERTIES | ||||||
|---|---|---|---|---|---|---|
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) | |
| 0..305 | 1.67 | 78 | 0.12 | 0.00000711 | 2510 | |
Yes, MP35N bars can be recycled after use. As a high-performance alloy, it can be melted down and reused to produce new components without significant loss of quality.
MP35N rods are sized based on their diameter and length, typically ranging from 1/16" to 6" diameter and custom lengths, depending on application requirements and manufacturing specifications.
MP35N rods are available in various sizes, typically ranging from 1/8" to 8" in diameter. Common finishes include cold drawn, hot rolled, and annealed for enhanced machinability and surface quality.
MP35N Bars and Rods find applications in a wide array of demanding situations that require strength, corrosion resistance, and durability. In the aerospace industry, they are used in fasteners, springs, and hydraulic systems due to their fatigue resistance. The medical field relies on MP35N for surgical implants, pacemaker leads, and orthopedic devices, thanks to its proven biocompatibility. In the oil and gas sector, it’s highly valued for its resistance to sulfide stress cracking and harsh chemical environments. Moreover, marine industries depend on MP35N Bars and Rods for components that are exposed to seawater and extreme operational conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
